Copper Port

10/100/1000Base-T   RJ45

SFP Port

100/1000BASE-X   SFP interfaces

Fiber Mode

1000BASE-X,   550m-160km, SC/ST/FC

Parameters

Ethernet Standards

IEEE 802.3   10BASE-T

IEEE 802.3u 100BASE-TX/100BASE-FX

IEEE 802.3ab Gigabit Ethernet
  IEEE 802.3z Gigabit Ethernet over Fiber Optic

IEEE 802.3x flow control and back pressure

Packet Length

2046bytes

Transmission Mode

Store and   Forward/Cut through

Exchange Property

Delay time:   < 7ps

Backplane bandwidth: 20Gbps; Packet forwarding rate: 14.88Mpps

DIP Switches

LFP   function:Disable/Enable

Fowrward mode:Store and forward/Cut through

Fiber Speed:FX 100M/1000M

LED Indicator

Power

Connect-always

RJ45

Link/Act:   connect-always; data exchange-twinkle

Fiber

Link/Act:   connect-always; data exchange-twinkle

Fiber Speed

FX 100M/1000M

Power Information

Power Input

Adapter Type:   DC 5-12V

Power Consumption

Full-load<3W

Physical Property

Dimensions

120mm×90mm×35mm

Installation Mode

wall-mountable

Weight

130g

Working Environment

Operating Temperature

0°C~50°C

Operating Humidity

10%~90%   non-condensing

Storage Temperature

-10°C~70°C

Warranty

MTBF

50,000 hours

Defects Liability Period

1 year   warranty, lifetime technical support

Certification Standard

EMC

FCC Part15   Class A

CE-EMC/LVD

RoHS

EN61000-4-2 (ESD), EN61000-4-3 (RS)

EN6100044 (EFT), EN6100045 (Surge)

EN61000^1-6 (CS), EN61000-4-8

EN61000-4-11
